Granite Multi-Saw Blade Cutting Machine

Our cutting machine can load 20-28 saw blades longitudinally. With high processing efficiency and good precision, it is an ideal granite processing equipment.

Item NO.:
LSDQ-20/28
Order(MOQ):
1
Payment:
T/T
Product Origin:
China
Shipping Port:
Xiamen Port
Lead Time：
15 days

Single Column Stone Cutting Machine

This machine is a special machine tool for cutting curb stones and strip stones. The cutting length can be customized according to the needs of users, which makes up for the processing defects on the length of the gantry stone cutting machine. The saw blade moves in and out, lifts and lowers electrically, the feed of the worktable is adjusted by the frequency converter, and the stone is automatically cut horizontally, with high work efficiency.

Bridge Single Blade Stone Cutting Machine

The bridge type single blade saw has a simple and reasonable structure and high stability. It adopts hydraulic sliding plate to lift, which has the characteristics of fast lifting speed, anti-wear, not easy to deform, and easy to maintain.

SMT High Efficiency Multi-Saw Stone Cutter

The machine has a high degree of automation, stable overall processing performance, high efficiency and low consumption. It is the most ideal stone machine for cutting strip stones, curb stones and monument stones.

Multi-Blade Hydraulic Stone Cutting Machine

This machine is optimized and improved on the basis of the combined saw. The machine adopts a four-column hydraulic locking structure, which has good overall rigidity and small clearance, which is conducive to reducing the shaking during the cutting stone, and the produced slabs have high precision. , the flatness is good. At the same time, it has achieved remarkable results in improving the service life of the segments and reducing power consumption.

SLQ600/800 Hand Stone Cutting Machine for Tombstone

This stone cutting machine can be used for cutting large stone carvings, brick carvings, inkstones, tombstones, floor stones, etc.

ANYTH Double Blades Stone Cutter

Double Blades Stone Cutter adopts a portal double column structure, oil-immersed track, horizontal electric variable frequency cutting, electric lifting, double saw blades, and an optional conveyor belt workbench, making it the best choice for stone cutting.

XQJ-600 Portable Marble Slabs Stone Cutting Table Saw Machine

XQJ-600 is a stone cutting table saw machine suitable for cutting stone, ceramic tile, brick, concrete and wood etc.

High Production Multi Blade Stone Cutting Machine

Multi blade stone cutting machine has the advantages of high cutting efficiency, high slicing accuracy, good flatness, high stability and simple operation. this machine is especially suitable for cutting high-value granite and marble blocks.

Model	LSDQ-20	LSDQ-28
Vertical disk No.	20pcs	28pcs
Voltage	380v-3phase,50hz	380v-3phase,50hz
Power motor for vertical disc	75kw	90kw
Power motor for horizontal disc	11kw	18kw
Power motor for bridge up-down stroke	3kw	3kw
Power motor for longitudinal traverse	2.2kw	2.2kw
Power motor for trolley truck displacement	2.2kw	2.2kw
Dia.of vertical blade	Ø900-Ø1300mm	Ø1200-Ø1600mm
Dia.of horizontal blade	450-600mm	450-600mm
Elevating speed of bridge stand	180mm/min	180mm/min
Cutting speed	0-8000mm/min	0-8000mm/min
Thickness of slice slab	8-140mm	8-140mm
Productivity	140㎡/8hrs	140㎡/8hrs
Size of trolley truck	2500x2100mm	2500x2100mm
Dimension of block	3200x2000x2000mm	3200x2000x2000mm
Overall dimension	6750x5160x5160mm	7900x6300x6300mm
Total gross weight	18000kgs	21000kgs
