Natural Stone and Concrete Block Hydraulic Splitting Machine

Our Hydraulic stone splitting machine is suitable for splitting all types of natural stones and concrete blocks, cube stone/curb stone/wall stone/blocks tone/tiles/paving stone/countertops/vanity tops.
  • Brand:

    HAINENG
  • Item NO.:

    SDKJ-40T/60T/80T/120T
  • Order(MOQ):

    1
  • Payment:

    T/T
  • Product Origin:

    China
  • Color:

    Yellow
  • Shipping Port:

    Xiamen Port
  • Lead Time:

    15 Days
Product Detail

Stone and Concrete Hydraulic Splitting Machine

The Stone Splitting Machine adopts a hydraulic drive design, which is evenly stressed and can split the stone into two cubes or blocks with a rustic appearance. It is used in the production of slab paving and finished slabs. It allows the execution of various works such as pavements, facades and village walls.


Performance Characteristics

1. Small size and easy to operate, users can use different blades to cut different materials. The blade is easy to install and efficient.
2. The use of high-strength cast iron and high-quality parts ensures working stability, and the special design of rapid lifting movement greatly improves work efficiency.
3. Reasonable structure, stable performance, precise cutting, and low wear.
4. The machine has a solid steel overall structure, and its shape is not easy to change during long-term operation.
5. The stone splitting machine is suitable for making cobblestones, paving stones, boundary stones, etc.


Main technical parameter:

Technical Data
Model No.
SDKJ-40T SDKJ-60T SDKJ-80T SDKJ-120T
Max.Pressure ton 40 60 120 120
Blade feeding speed mm/s 80 80 90 90
Max. working height mm 250 200 300 300
Max. working length mm 200 300 400 500
Output per hour m2/h 8 10 18 18
Power kw 7.5 11 11 11
Voltage / Frequency V / Hz 380 / 50 380 / 50 380 / 80 380 / 80
Flow rate L/M 41 41 47 47
Hydraulic oil grade # 46 46 46 46
Oil tank capacity L/kg 240 / 200 350/290 350/290 350/290
Gross weight kg 1300 1400 1900 2400
Dimensions ( L x W x H ) mm 1500x960x2000 1800x1050x2050 2100x1100x2300 2250x1100x2250


Processing

Hydraulic Stone Splitting Machine


Machine details

Concrete Splitting Machine

Stone Splitting Machine
